JIS Check Valve
Quantity
Inquiry

JIS Check Valve

JIS check valve is a valve which automatically opens and closes valve disc depending on the flow of the medium itself, and it is also used to prevent medium from flowing backwards. It is also called single direction valve, no-return valve and back pressure valve. It is a kind of automatic valve, main function of check valve is to prevent the reverse flow of the medium, prevent the reversal of the pump and drive motor, and the discharge of the container medium.

  • JIS Check Valve
  • JIS Check Valve
  • JIS Check Valve range:

Production Size: 2"-24" DN50-DN600mm.

Pressure: 10K.

  • JIS Check Valve Standard:

Design Standard: JIS B2031.

Face to Face: JIS B2031.

Flange Standard: JIS B2031.

Testing Standard: KS B 2304.

  • JIS Check Valve Main Material of Parts:

Body: FC20.

Bonnet: FC20.

Stem: 2Cr13/SS304/SS316/carbon steel.

Stem Nut: brass.

Disc: FC20.

Seat: bronze, brass.

Hanger: EN-GJS-5007.

Hanger Pin: stainless steel.

Cover Gasket: Graphite.
