- ANSI Cast Steel Rising Metal Gate Valve
Quantity
ANSI Cast Steel Rising Metal
ANSI Cast steel Gate Valve is widely used in petroleum, chemical, natural gas, electric power, metallurgy, pharmacy, building, water supply and other industries for three performances: availability, reliability and stability. All users rate our quality high.
This product is produced and designed according API standard with reliable sealing.
- ANSI Cast Steel Gate Valve Standard:
Production Size: 1/2"~40". DN15~DN1000.
Pressure: 150LB, 300LB, 600LB, 900LB.
Design Standard: API600, API6D.
Face to Face: ASME B16.34.
Flange Standard: ASME B16.10.
Testing Standard: ASME B16.25.
- ANSI Cast steel Gate Valve Material of Parts:
Body: ASTM A216 WCB.
Bonnet: ASTM A216 WCB.
Stem: 2Cr13, SS304, SS316, carbon steel.
Stem Nut: brass, ductile iron.
Disc: ASTM A216 WCB.
Seat: 13Cr13, stellite.
Handwheel: GGG45/GGG50.
