ANSI Thread End ISO Derect Mounting Pad Ball Valve 3PC
Quantity
Inquiry

ANSI Thread End ISO Derect Mounting Pad Ball Valve 3PC

ANSI Thread End ISO Derect Mounting Pad Ball Valve 3PC is widely used in petroleum refining, long-distance pipeline, chemical industry, paper, pharmaceutical, water conservancy, electric power, municipal, steel and other industries. It, the opening and closing (ball) is driven by the stem and revolves around the axis. The sealing performance is good, the seal of the hard sealed is made by artificial grinding until the valve core is in perfect agreement with the seal ring. So its sealing performance is reliable, the switch is light.

  • ANSI Thread End ISO Derect Mounting Pad Ball Valve 3PC
  • ANSI Thread End ISO Derect Mounting Pad Ball Valve 3PC
  • ANSI Thread End ISO Derect Mounting Pad Ball Valve 3PC Range:

Production Size: 1/2"~4". DN15~DN100.

Pressure: 1000PSI/PN63.

  • ANSI Stainless Steel Ball Valve Standard:

Design Standard: ANSI B16.34

Face to Face: ASME B16.10

Testing Standard: API 598

  • ANSI Thread End ISO Derect Mounting Pad Ball Valve 3PC Main Material of Parts:

Body: CF3, CF3M, CF8, CF8M.

Stem: 2Cr13/SS304/SS316.

Ball: CF3, CF3M, CF8, CF8M.

Packing: PTFE.

Seat: PTFE, RPTFE.

Washer: SUS304.

Handle: SUS304.

  • ANSI Thread End ISO Derect Mounting Pad Ball Valve 3PC
