Full Port 2000WOG 2PC Ball Valve
Quantity

Full Port 2000WOG 2PC Ball Valve

Full Port 2000WOG 2PC Ball Valve is widely used in petroleum refining, long-distance pipeline, chemical industry, paper, pharmaceutical, water conservancy, electric power, municipal, steel and other industries. It, the opening and closing (ball) is driven by the stem and revolves around the axis. The sealing performance is good, the seal of the hard sealed is made by artificial grinding until the valve core is in perfect agreement with the seal ring. So its sealing performance is reliable, the switch is light.

  • Full Port 2000WOG 2PC Ball Valve
  • Full Port 2000WOG 2PC Ball Valve
  • Full Port 2000WOG 2PC Ball Valve Range:

Production Size: 1/2"~4". DN15~DN100.

Pressure: 3000PSI/PN210.

  • Full Port 2000WOG 2PC Ball Valve Standard:

Design Standard: ANSI B16.34

Face to Face: ASME B16.10

Testing Standard: API 598

  • Full Port 2000WOG 2PC Ball Valve Main Material of Parts:

Body: CF3, CF3M, CF8, CF8M, WCB.

Stem: 2Cr13/SS304/SS316/carbon steel.

Ball: CF3, CF3M, CF8, CF8M.

Packing: PTFE.

Seat: PTFE, RPTFE.

Washer: SUS304.

Handle: SUS304.

  • Full Port 2000WOG 2PC Ball Valve
