ANSI 3000PSI Reducing Port 2PC Ball Valve
Quantity
Inquiry

ANSI 3000PSI Reducing Port 2PC Ball Valve

ANSI 3000PSI Reducing Port 2PC Ball Valve is widely used in petroleum refining, long-distance pipeline, chemical industry, paper, pharmaceutical, water conservancy, electric power, municipal, steel and other industries. It, the opening and closing (ball) is driven by the stem and revolves around the axis. The sealing performance is good, the seal of the hard sealed is made by artificial grinding until the valve core is in perfect agreement with the seal ring. So its sealing performance is reliable, the switch is light.

  • ANSI 3000PSI Reducing Port 2PC Ball Valve
  • ANSI 3000PSI Reducing Port 2PC Ball Valve
  • ANSI 3000PSI Reducing Port 2PC Ball Valve Range:

Production Size: 1/2"~2". DN15~DN50.

Pressure: 3000PSI/PN210.

  • ANSI 3000PSI Reducing Port 2PC Ball Valve Standard:

Design Standard: ANSI B16.34

Face to Face: ASME B16.10

Thread Standard: ASME B1.20/DIN 2999/DIN259/JIS B0203

Testing Standard: API 598

  • ANSI 3000PSI Reducing Port 2PC Ball Valve Main Material of Parts:

Body: CF3, CF3M, CF8, CF8M, WCB.

Stem: 2Cr13/SS304/SS316.

Ball: CF3, CF3M, CF8, CF8M.

Gland: PTFE.

Seat: PTFE, RPTFE.

Thrust Washer: SUS304.

Handle: SUS304.

  • ANSI 3000PSI Reducing Port 2PC Ball Valve
